Customizable 39mm 2 – pole Rotary Position Switch with 4 to 12 Positions

$3.29

Color: Blue
Material: Metals and Plastics
Operating temperature: – 150 °C~+70 °C
Rated power: DC30V
Swing life: 5000 cycles
Rated Current: 0.5/0.3A
Rotation Torque: 500 200gf.cm
Insulation resistance: 500VDC 100M Min
Service: Accept Customized
Certification: ISO8001/ISO14001/ISO13485/IATF16949

Quantity	Discount (%)	Price
1 - 9	—	$3.29
10 - 99	4.26 %	$3.15
100 - 999	9.12 %	$2.99
1,000 - 9,999	13.37 %	$2.85
10,000+	22.49 %	$2.55

Categories: Electronic Accessories, Switches, Rotate Move it Button Switch

Description
Reviews (0)

Description

Product Basics

The product is a multiplexer, with an overall dimension of 39mm. It is made of metal and plastic. Its operating characteristic is that the top finger rotates, providing a clear sense of rotation and positioning.

Product Features

With a long swing life of 5000 cycles, this multiplexer ensures durability and long – term reliable operation. Moreover, it is highly customizable. Users can choose from 2 – 12 gears, customize the shaft shape and length, and adjust the number of layers to meet specific requirements.

Application Scenarios

It is applicable to power amplifiers, stereos, and other household appliances. Its main functions include volume adjustment, facilitating various audio – related applications.
